Product Summary

The 25TQC22M is a dc/dc converter. It is perfect for high voltage, low ESR and low profile applications. The 25TQC22M is the most suitable for pass-con of the motor driver by 12V, the input of the DCDC converter.

Parametrics

25TQC22M specifications: (1)Operating Temperature range: －55 to + 105℃; (2)Rated capacitance range: 5.6 to 68 μF; (3)Capacitance tolerance: M:±20％; (4)Rated voltage: 16 to 25V.DC; (5)Dissipation FactorD.F.: ≦10.0％; (6)Leakage current μA: ≦0.1CV B2size:≦0.3CV.

Features

25TQC22M characteristics: (1)Rated Voltag V: 25 * 4; (2)Rated temperature ℃: 85; (3)Rated Capacitance μF: 22; (4)D.F. %max.: 10.0; (5)L.C. μA max./5min.: 44.0; (6)E.S.R. mΩmax. 100kHz/20℃: 90; (7)Maximum allowable ripple current mArms 100kHz×3: 1000.

Diagrams

25TQC22M dimensions
