Product Summary

The SP3232ECY-L is an RS-232 transceiver solution intended for portable or handheld applications such as notebook or palmtop computers. The SP3232ECY-L has a high-efficiency, charge-pump power supply that requires only 0.1μF capacitors in 3.3V operation. The SP3232ECY-L is a 2-receiver device. It is ideal for portable or hand-held applications such as notebook or palmtop computers. The ESD tolerance of the SP3232ECY-L is over ±15kV for both Human Body Model and IEC1000-4-2 Air discharge test methods. The SP3232ECY-L has a low-power shutdown mode where the driver outputs and charge pumps are disabled. During shutdown, the supply current falls to less than 1μA.

Parametrics

SP3232ECY-L absolute maximum ratings: (1)VCC: -0.3V to +6.0V; (2)V+: -0.3V to +7.0V; (3)V-: +0.3V to -7.0V; (4)V+ + |V-|: +13V; (5)ICC (DC VCC or GND current): ±100mA; (6)TxIN, EN: -0.3V to +6.0V; (7)RxIN: ±15V; (8)TxOUT: ±15V; (9)RxOUT: -0.3V to (VCC + 0.3V); (10)TxOUT: Continuous; (11)Storage Temperature: -65℃ to +150℃.

Features

SP3232ECY-L features: (1)Meets true EIA/TIA-232-F Standards from a +3.0V to +5.5V power supply; (2)Minimum 120Kbps Data Rate Under Full Load; (3)Interoperable with RS-232 down to +2.7V power source; (4)Enhanced ESD Specifications: ±15kV Human Body Model; ±15kV IEC1000-4-2 Air Discharge; ±8kV IEC1000-4-2 Contact Discharge.

Diagrams

SP3232ECY-L diagram
