T491A104K050AT

Tantalum Surface Mount Capacitor, 0.1uF, 50V, 10%, SMD, RoHS Compliant

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.25~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.25~0.50

PartNumber:: T491A104K050AT

Brand:: Kemet Corporation - KEMET | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Mark Mak's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-01

From Other Seller

Part Number:T491A104K050AT
US $0.25 - 0.50
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The T491A104K050AT is a Standard MnO2 Tantalum Surface Mount Capacitor. The T491A104K050AT combines KEMET’s proven solid tantalum technology, acclaimed and respected throughout the world, with the latest in materials, processes and automation, resulting in unsurpassed total performance and value. The T491A104K050AT meets or exceeds the requirements of EIA Standard 535BAAC. The physical outline and dimensions of this series conform to this global standard. Typical applications of the T491A104K050AT include decoupling and fltering in industrial and automotive end applications such as DC/DC converters, portable electronics, telecommunications, and control units.

Parametrics

T491A104K050AT general specifications: (1)Operating Temperature:-55℃ to 125℃; (2)Rated Capacitance Range:0.1 to 1,000 μF @ 120 Hz/25℃; (3)Capacitance Tolerance:K Tolerance (10%), M Tolerance (20%); (4)Rated Voltage Range:2.5 to 50 V; (5)DF (120 Hz):Refer to Part Number Electrical Specifcation Table ; (6)ESR (100 kHz):Refer to Part Number Electrical Specifcation Table ; (7)Leakage Current: ≤ 0.01 CV (μA) at Rated Voltage after 5 minutes.

Features

T491A104K050AT features: (1)Meets or Exceeds EIA Standard 535BAAC; (2)Taped and Reeled per EIA 481–D; (3)Symmetrical, Compliant Terminations; (4)Optical Gold-Plated Terminations; (5)Laser-marked Case; (6)100% Surge current test on C, D, E, U, V, X sizes; (7)Halogen Free Epoxy; (8)Capacitance 0.1 μF to 1,000 μF; (9)Tolerance ±10%, ±20%; (10)Voltage 2.5 to 50 VDC; (11)Extended Range Values; (12)Low Profle Case Sizes; (13)RoHS Compliant and Lead Free Terminations; (14)Operating Temperature: -55 to +125℃.
